| Functions | Grid Breaker Control, Auto Synchronization, Two breaker controls, Multiple grid controls |
|---|---|
| Name | Grid Breaker Controller |
| Auxiliary Voltage | 8 to 40 V DC |
| Power Consumption | 6 W |
| Digital Outputs | 6 |
| Digital Inputs | 8 |
| Mounting Type | Door Mounting |
| Degree of Protection | Front - IP40, Back - IP20 |
| Nominal Frequency | 50 / 60 Hz |
| Analog Inputs | 0 |
| Analog Outputs | 0 |
| Functions | Grid Breaker Control, Auto Synchronization, Two breaker controls, Multiple grid controls, Import/Export Control |
|---|---|
| Name | Grid Breaker Controller |
| Auxiliary Voltage | 8 to 40 V DC |
| Power Consumption | 6 W |
| Digital Outputs | 6 |
| Digital Inputs | 8 |
| Mounting Type | Back Panel Mounting |
| Degree of Protection | Front - IP40, Back - IP20 |
| Nominal Frequency | 50 / 60 Hz |
| Analog Inputs | 3 |
| Analog Outputs | 2 |
